Distro - 32A 3P MDU
Specifications
- 32 A 415 V three-phase inlet (3P+N+E), IP44
- 6 x 16 A outlets, each on a 30 mA Type C RCBO
- 196 x 285 x 290 mm (H x W x D), 2.8 kg
The 32A 3P MDU is an eLumen8 IMST mains distribution box fed from a 32 A three-phase supply. It has a 32 A 415 V 3P+N+E IP44 inlet and six 16 A 2P+E IP44 outlets, each protected by its own 16 A 30 mA two-pole Type C RCBO. The housing is shock-resistant polyamide with a folding steel carry handle, is rated IP44 and stacks with others of the same type. It measures 196 x 285 x 290 mm (H x W x D) and weighs 2.8 kg on Cloud One's own scales, against a published 2.9 kg.
Available for hire across Birmingham and the UK. Need advice? Call 0121 333 7711 or send an enquiry.
