Steel Wire Rope Loop (Soft & Hard Eye)
Specifications
- Working load limits 100 kg - 1,000 kg
- Lengths 0.5 m - 13.2 m
- Hard (thimbled) eye, soft eye, or one of each; some PVC sheathed
The Steel Wire Rope Loop is a wire rope strop terminated with one soft eye and one hard eye, used to hang loads from structural steel and truss. The soft eye is a plain spliced loop that can be wrapped around a beam and passed back through the hard eye; the hard eye is formed over a thimble so that a shackle or hook bears on metal rather than on the rope itself. Cloud One's stock record lists steels at 100 kg, 150 kg, 250 kg, 400 kg, 760 kg and 1,000 kg, in lengths from 0.5 m to 13.2 m, with hard loops, soft loops or one of each, and some sheathed in PVC.
Available for hire across Birmingham and the UK. Need advice? Call 0121 333 7711 or send an enquiry.
