Shure P10T IEM Transmitter
Specifications
- Two XLR / 6.35 mm TRS combo inputs, electronically balanced
- RF output selectable 10 / 50 / 100 mW
- Tuning bandwidth 72 - 80 MHz; 1U, 44 x 483 x 343 mm
The Shure P10T is a full-rack, dual-channel transmitter for the PSM 1000 personal monitor system, used with P10R+ bodypack receivers. Audio inputs are two electronically balanced combination XLR and 6.35 mm TRS sockets with nominal input level switchable between +4 dBu and -10 dBV, plus a 6.35 mm TRS loop output. RF output is selectable at 10, 50 or 100 mW into 50 Ω, and tuning bandwidth is 72 - 80 MHz depending on region. A two-port RJ-45 Ethernet jack allows remote control and frequency coordination from Wireless Workbench, and the unit measures 44 x 483 x 343 mm and weighs 4.7 kg.
Available for hire across Birmingham and the UK. Need advice? Call 0121 333 7711 or send an enquiry.
More Audio Equipment
L-Acoustics KARA II
The L-Acoustics KARA II is a two-way line source element with two 8" neodymium cone drivers and one 3" neodymium diaphragm compression driver. Panflex variable L-Fins set the horizontal directivity to 70 or 110° symmetric, or 90° asymmetric. The four-point captive rigging system allows inter-enclosure angles from 0 to 10°, and the enclosure weighs 26 kg and connects on two 4-point speakON sockets. It is driven by the LA4X, LA8 or LA12X amplified controller.
View details →
Yamaha DM7 Compact
The Yamaha DM7 Compact is a digital mixing console with 72 mono input channels, 48 mix buses, 12 matrices, two stereo buses and two cue buses. The surface has 12 channel faders plus four masters, 12.1-inch and 7-inch multi-touch displays, 16 analogue inputs, 16 analogue outputs, a two-channel AES/EBU output and one PY slot. Dante primary and secondary ports carry 144 input and 144 output channels, and Split Mode allows front of house and monitors to run from one surface. A dual power supply is built in, the Dan Dugan automixer covers 64 channels, and the RK1 kit rack-mounts it.
View details →
L-Acoustics KS28
The L-Acoustics KS28 is a subwoofer with two 18" neodymium cone drivers in a bass-reflex enclosure fitted with L-Vents laminar vents to reduce port turbulence. Its low frequency limit is 25 Hz at -10 dB, and it can be set for standard or cardioid directivity by combining the physical deployment with the matching preset. The cabinet is Baltic beech and birch plywood, rated IP55, measures 1340 x 550 x 719 mm and weighs 79 kg. Connection is on a single 4-point speakON socket and it is driven by the LA12X amplified controller.
View details →
