Riedel Bolero Interface Kit
Specifications
- Model 45A - 2 interface channels, 2-wire to 4-wire, XLR
- NSA-002A - 6 analogue inputs / 6 outputs (XLR3), 3 GPI / 3 GPO (D-Sub-9)
- NSA-002A - 2 x RJ45 AES67 ports, mains 100 - 240 V or PoE
The Riedel Bolero Interface Kit is a pair of interface units used to connect a Bolero wireless intercom system to analogue circuits. The Studio Technologies Model 45A gives two channels of interfacing between a 2-wire party-line intercom circuit, such as those used by RTS and Clear-Com systems, and a 4-wire analogue circuit. The Riedel NSA-002A handles conversion between analogue audio and AES67 in both directions, carrying six balanced 4-wire inputs and six outputs on XLR3 plus three GPI inputs and three GPO outputs on D-Sub-9.
Available for hire across Birmingham and the UK. Need advice? Call 0121 333 7711 or send an enquiry.
