Manfrotto 083NW Wind-up Stand
Specifications
- Maximum height 247 cm, closed length 153 cm
- Payload 45 kg (30 kg at maximum extension)
- Weight 16 kg
The Manfrotto 083NW is a two-section chrome-plated steel wind-up stand with a single riser, used to hold lighting fixtures and similar loads. It winds from a closed length of 153 cm to a maximum height of 247 cm and carries a payload of 45 kg, or 30 kg at maximum extension. The top takes a 1 1/8" (28 mm) socket, a 5/8" (16 mm) stud or a 3/8" screw attachment, and one of the three legs is a levelling leg for uneven ground. The stand weighs 16 kg and accepts Manfrotto 104, 104G and 374-10 wheels.
Available for hire across Birmingham and the UK. Need advice? Call 0121 333 7711 or send an enquiry.
